Below are some architectural guidelines all architects shall take into considerations while adopting our panel full system load bearing system.
For further details please communicate with our engineering division.
- 1. Vertical wall panels, floor, roof slabs panels and lintels combine to form complete precast system as load bearing structure buildings.
- 2. The maximum span of A.A.C panels is 6m which means clear span dimensions between the load bearing walls should not exceed 5.80m.
- 3. We will use a steel or concrete beam to support the slabs if the clear span is more than 5.80m.
- 4. Direct support of wall panel on floor slabs is not allowed without steel or concrete beams support but 10 cm to be thickness non-bearing partition wall can be directly placed taking into account its land property.
- 5. We prefer 3 meters story heights to get full mold utilization by cutting 6 meters mold into half. Other heights are also possible.
- 6. Try to design according to 600 mm modules for zone dimensions or for windows openings. Which means multiple of 1000mm for sizes of rooms and windows in plan.
- 7. Non modular windows openings width also can be formed with cut panels preferably 300 mm width as additional to standard multiple of 600mm.
- 8. Doors are generally made to required size but we prefer door height to be 2400 mm in height to fit a 600 mm height horizontal panel and reach a total of 3,000mm room height.
- 9. A.C units are normally 700 mm. We advise to specify 600mm width Window AC to avoid cutting in wall panels.
- 10. Exhaust fan ducts are best centered on wall panel joints.
- 11. Is preferred to be 600 mm for both sides but minimum and supports.250 to 300mm can also be used us.
